Neural Networks explained with spreadsheets, 3: Training a single neuron

Training a single neuron

Hi all, here’s the third on my series on neural networks / machine learning / AI from scratch. In the previous articles (please read them first!), I explained how a single neuron works, and how to calculate the gradient of its weight and bias. In this article, I’ll explain how you can use those gradients to train the neuron.

Spreadsheet

I recommend opening this spreadsheet in a separate tab, and viewing it as you read this post which explains the maths: Single neuron training.

In case the linked spreadsheet is lost to posterity, here it is in slightly less well-formatted form (note: for brevity’s sake, I’ve shortened references such as B2 to simply ‘B’ when referring to a column in the same row):

	A	C	D	F	G	H	I	J	K	L	N	O	P	Q
1	Learning rate	Training		Neuron							Outputs
2	0.1	In	Out	Input	Weight	Weight gradient	Bias	Bias gradient	Net	Output	Target	Attempt	Error	Loss
3		0.01	0.1 (C*10)	0.01 (C)	0.5	J * F	0.5	P * (1-L²)	F*G+I	Tanh(K)	0.1 (D)	1	L-N	P² / 2
4		0.01	0.1 (C*10)	0.01 (C)	G3 - H3 * LEARNING_RATE	J * F	I3 - J3 * LEARNING_RATE	P * (1-L²)	F*G+I	Tanh(K)	0.1 (D)	2	L-N	P² / 2
5		0.01	0.1 (C*10)	0.01 (C)	G4 - H4 * LEARNING_RATE	J * F	I4 - J4 * LEARNING_RATE	P * (1-L²)	F*G+I	Tanh(K)	0.1 (D)	3	L-N	P² / 2

High level explanation

Note: “Parameters” is the umbrella term for “weights and biases”.

Row 3 starts with any old values for the parameters.
Row 4 optimises the parameters a little to decrease the error.
Row 5.1000 repeat this optimisation process, aka ‘gradient descent’.
Eventually the optimised parameters will produce the output we want!

Detailed explanation

A2 is the ‘learning rate’. This governs how much we ‘nudge’ our weight/bias each iteration. In this example it’s higher than a more common 0.1% - 1%.

Columns C-D are the ‘training data’. In this example we want to train the neuron to multiply by 10.

Columns F-L are the neuron maths, as covered by my earlier articles. The two gradients in particular are tricky and important: They dictate which direction the bias/weight should respectively be ‘nudged’ to decrease the error.

Columns N-Q are the outputs, and useful for producing the neat graph you’ll hopefully see in the actual spreadsheet, which demonstrates how the error decreases over the iterations.

Row 3 is the initial data. At this point in a real implementation we would typically choose random values for the initial bias and weight, however I’ve chosen 0.5 to start with because it’s a nice round number.

🧨💣💥 Rows 4+ are the same as row 3, except that the parameters have some of their gradient subtracted each time. (this is the important bit)

Incidentally, this might help explain why training a NN uses a lot more computation than using it: Because of all the gradient calculations and iterations over training data.

And there you have it, that’s how to use the gradients to train a single neuron. Next I’ll explain how to calculate the gradients for a network of them!

Rust demo

Because I’m a Rust tragic, here’s a demo:

const LEARNING_RATE: f64 = 0.01;
const TRAINING_INPUT: f64 = 0.01;
const TRAINING_OUTPUT: f64 = 0.1;

fn main() {
    // Initial parameters.
    let mut weight: f64 = 0.5;
    let mut bias: f64 = 0.5;

    // Train.
    for _ in 0..100_000 {
        let net = TRAINING_INPUT * weight + bias;
        let output = net.tanh();
        let error = output - TRAINING_OUTPUT;
        let loss = error * error / 2.;
        let bias_gradient = error * (1. - output * output);
        let weight_gradient = bias_gradient * TRAINING_INPUT;
        weight -= weight_gradient * LEARNING_RATE;
        bias -= bias_gradient * LEARNING_RATE;
    }

    // Use the trained parameters:
    let trained_net = TRAINING_INPUT * weight + bias;
    let trained_output = trained_net.tanh();
    println!("Trained output: {}", trained_output);
}

Which outputs:

Trained output: 0.1000000000000007

Which matches the training output nicely!

Thanks for reading, hope you found this helpful, at least a tiny bit, God bless!
